Hikvision DS-7108HGHI-M1/T 08 Channel Mini 1U DVR

Specification
Audio and Video
IP Camera Input
2-ch (up to 10-ch)
Up to 1080p resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
Display
Resolution
HDTVI Input: 1080p25, 1080p30, 720p25, 720p30
AHD Input: 1080p25, 1080p30, 720p25, 720p30
HDCVI Input: 1080p25, 1080p30, 720p25, 720p30
CVBS Input: Support
HDMI Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Recording
Compression
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Resolution
For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF
For 720p stream access: 720p/WD1/4CIF/VGA/CIF
For SD stream access: WD1/4CIF/VGA/CIF
Record Rate
Main stream: For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fps
For 720p stream access: 720p/WD1/4CIF/VGA/CIF@15 fps
For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
Sub-stream: 4CIF@15fps; CIF/QVGA@25 fps (P)/30 fps (N)
Bit Rate
32 Kbps to 4 Mbps
Others
Stream Type: Video, Video & Audio
Audio Compression: G.711u
Audio Bitrate: 64 Kbps
Video Detection And Alarm
Alarm Input
N/A
Playback And Backup
Sync Playback
8-ch
Search Mode
Quick search by object or event type is supported
Network
Ethernet Port
1, RJ45 10/100 Mbps self-adaptive Ethernet interface
Network Function
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,UPnP, HTTPS
Storage
Internal HDD
1 SATA interface
Up to 4 TB capacity for each disk
Auxiliary Interface
USB
2 × USB 2.0
Power
Power Supply
12 VDC, 1.5 A
Power Consumption
≤ 10 W (without HDD)
Component Environment
Operational Conditions
-10 °C to 55 °C (14 °F to +131 °F)
Construction
Dimensions
200 × 200 × 48 mm (7.9 × 7.9 × 1.9 inch)
Net Weight
≤ 1 kg (without HDD, 2.2 lb.)
Warranty
Manufacturing Warranty
1 Year
